2J7V

Structure of PBP-A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.172
  • R-Value Observed: 0.174

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Structure of Pbp-A from Thermosynechococcus Elongatus, a Penicillin-Binding Protein Closely Related to Class a Beta-Lactamases.

Urbach, C.Evrard, C.Pudzaitis, V.Fastrez, J.Soumillion, P.Declercq, J.P.

(2009) J Mol Biol 386: 109

  • DOI: https://doi.org/10.1016/j.jmb.2008.12.001
  • Primary Citation of Related Structures:
    2J7V, 2J8Y, 2J9O, 2JBF

  • PubMed Abstract:

    Molecular evolution has always been a subject of discussions, and researchers are interested in understanding how proteins with similar scaffolds can catalyze different reactions. In the superfamily of serine penicillin-recognizing enzymes, D-alanyl-D-alanine peptidases and beta-lactamases are phylogenetically linked but feature large differences of reactivity towards their respective substrates. In particular, while beta-lactamases hydrolyze penicillins very fast, leading to their inactivation, these molecules inhibit d-alanyl-d-alanine peptidases by forming stable covalent penicilloyl enzymes. In cyanobacteria, we have discovered a new family of penicillin-binding proteins (PBPs) presenting all the sequence features of class A beta-lactamases but having a six-amino-acid deletion in the conserved Omega-loop and lacking the essential Glu166 known to be involved in the penicillin hydrolysis mechanism. With the aim of evolving a member of this family into a beta-lactamase, PBP-A from Thermosynechococcus elongatus has been chosen because of its thermostability. Based on sequence alignments, introduction of a glutamate in position 158 of the shorter Omega-loop afforded an enzyme with a 50-fold increase in the rate of penicillin hydrolysis. The crystal structures of PBP-A in the free and penicilloylated forms at 1.9 A resolution and of L158E mutant at 1.5 A resolution were also solved, giving insights in the catalytic mechanism of the proteins. Since all the active-site elements of PBP-A-L158E, including an essential water molecule, are almost perfectly superimposed with those of a class A beta-lactamase such as TEM-1, the question why our mutant is still 5 orders of magnitude less active as a penicillinase remains and our results emphasize how far we are from understanding the secrets of enzymes. Based on the few minor differences between the active sites of PBP-A and TEM-1, mutations were introduced in the L158E enzyme, but while activities on D-Ala-D-Ala mimicking substrates were severely impaired, further improvement in penicillinase activity was unsuccessful.


  • Organizational Affiliation

    Laboratoire d'Ingénierie des Protéines et des Peptides, Institut des Sciences de la Vie, Université catholique de Louvain, Place Croix du Sud 4-5, bte3, 1348 Louvain la-Neuve, Belgium.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
TLL2115 PROTEIN
A, B, C, D
298Synechococcus elongatusMutation(s): 0
EC: 3.4.16.4
UniProt
Find proteins for Q8DH45 (Thermosynechococcus vestitus (strain NIES-2133 / IAM M-273 / BP-1))
Explore Q8DH45
Go to UniProtKB:  Q8DH45
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8DH45
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free: 0.213
  • R-Value Work: 0.172
  • R-Value Observed: 0.174
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.79α = 90
b = 91.9β = 90
c = 147.27γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-11-06
    Type: Initial release
  • Version 1.1: 2011-06-09
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2019-05-08
    Changes: Data collection, Experimental preparation, Other
  • Version 1.4: 2019-07-24
    Changes: Data collection
  • Version 1.5: 2023-12-13
    Changes: Data collection, Database references, Other, Refinement description
