2IHT

Carboxyethylarginine synthase from Streptomyces clavuligerus: SeMet structure


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.178
  • R-Value Work: 0.154
  • R-Value Observed: 0.154

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structural and mechanistic studies on N(2)-(2-carboxyethyl)arginine synthase.

Caines, M.E.Sorensen, J.L.Schofield, C.J.

(2009) Biochem Biophys Res Commun 385: 512-517

  • DOI: https://doi.org/10.1016/j.bbrc.2009.05.095
  • Primary Citation of Related Structures:
    2IHT, 2IHU, 2IHV

  • PubMed Abstract:

    N(2)-(2-Carboxyethyl)arginine synthase (CEAS), an unusual thiamin diphosphate (ThDP)-dependent enzyme, catalyses the committed step in the biosynthesis of the b-lactamase inhibitor clavulanic acid in Streptomyces clavuligerus. Crystal structures of tetrameric CEAS-ThDP in complex with the substrate analogues 5-guanidinovaleric acid (GVA) and tartrate, and a structure reflecting a possible enol(ate)-ThDP reaction intermediate are described. The structures suggest overlapping binding sites for the substrates D-glyceraldehyde-3-phosphate (D-G3P) and L-arginine, and are consistent with the proposed CEAS mechanism in which D-G3P binds at the active site and reacts to form an alpha,beta-unsaturated intermediate,which subsequently undergoes (1,4)-Michael addition with the alpha-amino group of L-arginine. Additional solution studies are presented which probe the amino acid substrate tolerance of CEAS, providing further insight into the L-arginine binding site. These findings may facilitate the engineering of CEAS towards the synthesis of alternative beta-amino acid products.


  • Organizational Affiliation

    Department of Chemistry, University of Oxford, Chemistry Research Laboratory, Oxford OX13TA, United Kingdom.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carboxyethylarginine synthase
A, B, C, D
573Streptomyces clavuligerusMutation(s): 11
Gene Names: ceas2
EC: 2.5.1.66
UniProt
Find proteins for Q9LCV9 (Streptomyces clavuligerus)
Explore Q9LCV9
Go to UniProtKB:  Q9LCV9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9LCV9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TPP
Query on TPP

Download Ideal Coordinates CCD File
H [auth A],
M [auth B],
R [auth C],
V [auth D]
THIAMINE DIPHOSPHATE
C12 H19 N4 O7 P2 S
AYEKOFBPNLCAJY-UHFFFAOYSA-O
SO4
Query on SO4

Download Ideal Coordinates CCD File
F [auth A]
G [auth A]
K [auth B]
L [auth B]
P [auth C]
F [auth A],
G [auth A],
K [auth B],
L [auth B],
P [auth C],
Q [auth C],
T [auth D],
U [auth D]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
I [auth A],
N [auth B],
W [auth D],
X [auth D]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
E [auth A],
J [auth B],
O [auth C],
S [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A, B, C, D
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.00 Å
  • R-Value Free: 0.178
  • R-Value Work: 0.154
  • R-Value Observed: 0.154
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 117.882α = 90
b = 127.279β = 90
c = 197.328γ = 90
Software Package:
Software NamePurpose
SCALAdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
MOSFLMdata reduction
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2007-09-18
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Non-polymer description, Version format compliance
  • Version 1.2: 2023-08-30
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.3: 2023-11-15
    Changes: Data collection
  • Version 1.4: 2024-10-30
    Changes: Structure summary
