2I7H | pdb_00002i7h

Crystal Structure of the Nitroreductase-like Family Protein from Bacillus cereus

• PDB DOI: https://doi.org/10.2210/pdb2I7H/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Bacillus cereus
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2006-08-30 Released: 2006-10-03
• Deposition Author(s): Kim, Y., Li, H., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.213 (Depositor), 0.208 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.176 (Depositor)

Literature

Crystal Structure of the Nitroreductase-like Family Protein from Bacillus cereus

Kim, Y., Li, H., Moy, S., Joachimiak, A.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 assigned by authors and generated by PISA (software)

Biological Assembly 4

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 4 generated by PISA (software)

Biological Assembly 5

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 5 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 133.28 kDa
• Atom Count: 10,972
• Modeled Residue Count: 1,120
• Deposited Residue Count: 1,134
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nitroreductase-like family protein	A, B, C, D, E, F	189	Bacillus cereus	Mutation(s): 4  Gene Names: BC_0786
UniProt
Find proteins for Q81HL8 (Bacillus cereus (strain ATCC 14579 / DSM 31 / CCUG 7414 / JCM 2152 / NBRC 15305 / NCIMB 9373 / NCTC 2599 / NRRL B-3711)) Explore Q81HL8  Go to UniProtKB:  Q81HL8

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
FMN	G [auth A], J [auth B], M [auth C], O [auth D]	FLAVIN MONONUCLEOTIDE C17 H21 N4 O9 P FVTCRASFADXXNN-SCRDCRAPSA-N
SO4	H [auth B], I [auth B], K [auth C], L [auth C], N [auth D], P [auth E], Q [auth F]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B, C, D, E, F	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.213 (Depositor), 0.208 (DCC)
• R-Value Work:  0.172 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.176 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 242.719	α = 90
b = 87.217	β = 103.03
c = 81.189	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SBC-Collect	data collection
HKL-2000	data reduction
HKL-2000	data scaling
HKL-3000	phasing
SHARP	phasing
SHELXD	phasing
SHELXE	model building
MLPHARE	phasing
SOLVE	phasing
RESOLVE	phasing
ARP/wARP	model building
Coot	model building

Structure Validation

Entry History

Deposition Data

• Released Date: 2006-10-03
Deposition Author(s): Kim, Y., Li, H., Moy, S., Joachimiak, A., Midwest Center for Structural Genomics (MCSG)

Revision History

• Version 1.0: 2006-10-03
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Refinement description, Version format compliance
• Version 1.3: 2024-10-30
  Changes: Data collection, Database references, Derived calculations, Structure summary
