2HHZ | pdb_00002hhz

Crystal structure of a pyridoxamine 5'-phosphate oxidase-related protein (ssuidraft_2804) from streptococcus suis 89/1591 at 2.00 A resolution

PDB DOI: https://doi.org/10.2210/pdb2HHZ/pdb

Classification: OXIDOREDUCTASE
Organism(s): Streptococcus suis 89/1591
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2006-06-28 Released: 2006-08-15
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.231 (Depositor), 0.239 (DCC)
R-Value Work:
0.191 (Depositor), 0.198 (DCC)
R-Value Observed:
0.193 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 2HHZ

This is version 1.5 of the entry. See complete history.

Literature

Crystal structure of Pyridoxamine 5'-phosphate oxidase-related (ZP_00875725.1) from STREPTOCOCCUS SUIS 89-1591 at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 17.67 kDa
Atom Count: 1,182
Modeled Residue Count: 139
Deposited Residue Count: 150
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pyridoxamine 5'-phosphate oxidase-related	A	150	Streptococcus suis 89/1591	Mutation(s): 7 Gene Names: ZP_00875725.1 EC: 1.4.3.5

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.231 (Depositor), 0.239 (DCC)
R-Value Work: 0.191 (Depositor), 0.198 (DCC)
R-Value Observed: 0.193 (Depositor)

Diffraction Data:

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 71	α = 90
b = 71	β = 90
c = 58.4	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
SHELXE	model building
autoSHARP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2006-08-15

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2006-08-15
Type: Initial release
Version 1.1: 2008-05-01
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Derived calculations, Source and taxonomy, Version format compliance
Version 1.3: 2017-10-18
Changes: Refinement description
Version 1.4: 2023-01-25
Changes: Database references, Derived calculations
Version 1.5: 2024-11-20
Changes: Data collection, Structure summary
