2CUK

Crystal structure of TT0316 protein from Thermus thermophilus HB8

• PDB DOI: https://doi.org/10.2210/pdb2CUK/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Thermus thermophilus HB8
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2005-05-26 Released: 2006-08-15
• Deposition Author(s): Lokanath, N.K., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.223
• R-Value Work: 0.185
• R-Value Observed: 0.185

Starting Model: experimental

Literature

Crystal structure of TT0316 protein from Thermus thermophilus HB8

Lokanath, N.K., Kunishima, N.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 135.69 kDa
• Atom Count: 10,539
• Modelled Residue Count: 1,244
• Deposited Residue Count: 1,244
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
glycerate dehydrogenase/glyoxylate reductase	A, B, C, D	311	Thermus thermophilus HB8	Mutation(s): 0  EC: 1.1.1
UniProt
Find proteins for Q5SMG6 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SMG6  Go to UniProtKB:  Q5SMG6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NHE	E [auth C]	2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID C8 H17 N O3 S MKWKNSIESPFAQN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free: 0.223
• R-Value Work: 0.185
• R-Value Observed: 0.185
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.774	α = 90
b = 52.235	β = 102.26
c = 161.433	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data reduction
SCALEPACK	data scaling
CNS	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2006-08-15
Deposition Author(s): Lokanath, N.K., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2006-08-15
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Source and taxonomy, Version format compliance
• Version 1.3: 2023-10-25
  Changes: Data collection, Database references, Derived calculations, Refinement description
