2A6H | pdb_00002a6h

Crystal structure of the T. thermophilus RNA polymerase holoenzyme in complex with antibiotic sterptolydigin


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.268 (Depositor), 0.263 (DCC)
  • R-Value Work:
    0.230 (Depositor), 0.229 (DCC)
  • R-Value Observed:
    0.230 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 2A6H

Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history

Literature

Structural basis of transcription inhibition by antibiotic streptolydigin.

Temiakov, D.Zenkin, N.Vassylyeva, M.N.Perederina, A.Tahirov, T.H.Kashkina, E.Savkina, M.Zorov, S.Nikiforov, V.Igarashi, N.Matsugaki, N.Wakatsuki, S.Severinov, K.Vassylyev, D.G.

(2005) Mol Cell 19: 655-666

  • DOI: https://doi.org/10.1016/j.molcel.2005.07.020
  • Primary Citation Related Structures:
    2A6H

  • PubMed Abstract:

    Streptolydigin (Stl) is a potent inhibitor of bacterial RNA polymerases (RNAPs). The 2.4 A resolution structure of the Thermus thermophilus RNAP-Stl complex showed that, in full agreement with the available genetic data, the inhibitor binding site is located 20 A away from the RNAP active site and encompasses the bridge helix and the trigger loop, two elements that are considered to be crucial for RNAP catalytic center function. Structure-based biochemical experiments revealed additional determinants of Stl binding and demonstrated that Stl does not affect NTP substrate binding, DNA translocation, and phosphodiester bond formation. The RNAP-Stl complex structure, its comparison with the closely related substrate bound eukaryotic transcription elongation complexes, and biochemical analysis suggest an inhibitory mechanism in which Stl stabilizes catalytically inactive (preinsertion) substrate bound transcription intermediate, thereby blocking structural isomerization of RNAP to an active configuration. The results provide a basis for a design of new antibiotics utilizing the Stl-like mechanism.


  • Organizational Affiliation
    • Department of Cell Biology, School of Osteopathic Medicine, University of Medicine and Dentistry of New Jersey, Stratford, New Jersey 08084, USA.

Macromolecule Content

  • Total Structure Weight: 854.78 kDa
  • Atom Count: 60,908
  • Modeled Residue Count: 6,796
  • Deposited Residue Count: 7,590
  • Unique protein chains: 5

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase alpha chainA,
B,
G [auth K],
H [auth L]
315Thermus thermophilusMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q5SHR6 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SHR6
Go to UniProtKB:  Q5SHR6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SHR6
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase beta chainC,
I [auth M]
1,119Thermus thermophilusMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE9 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE9
Go to UniProtKB:  Q8RQE9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE9
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase beta' chainD,
J [auth N]
1,524Thermus thermophilusMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE8 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE8
Go to UniProtKB:  Q8RQE8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE8
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA polymerase omega chainE,
K [auth O]
99Thermus thermophilusMutation(s): 0
EC: 2.7.7.6
UniProt
Find proteins for Q8RQE7 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q8RQE7
Go to UniProtKB:  Q8RQE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8RQE7
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
RNA polymerase sigma factor rpoDF,
L [auth P]
423Thermus thermophilusMutation(s): 0
UniProt
Find proteins for Q5SKW1 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8))
Explore Q5SKW1
Go to UniProtKB:  Q5SKW1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5SKW1
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
STD

Query on STD



Download:Ideal Coordinates CCD File
M [auth D],
Q [auth N]
STREPTOLYDIGIN
C32 H44 N2 O9
KVTPRMVXYZKLIG-NCAOFHFGSA-N
ZN

Query on ZN



Download:Ideal Coordinates CCD File
N [auth D],
O [auth D],
R [auth N],
S [auth N]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG

Query on MG



Download:Ideal Coordinates CCD File
P [auth D],
T [auth N]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.268 (Depositor), 0.263 (DCC)
  • R-Value Work:  0.230 (Depositor), 0.229 (DCC)
  • R-Value Observed: 0.230 (Depositor)
Space Group: P 32
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 239.5α = 90
b = 239.5β = 90
c = 253.1γ = 120
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
AMoREphasing
CNSrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2005-09-20
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-23
    Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
