24XX | pdb_000024xx

Cryo-EM Structure of a 12mer MucD cage

PDB DOI: https://doi.org/10.2210/pdb24XX/pdb
EM Map EMD-69903: EMDB EMDataResource

Classification: HYDROLASE
Organism(s): Pseudomonas aeruginosa PAO1
Expression System: Pseudomonas aeruginosa PAO1
Mutation(s): Yes

Deposited: 2026-03-24 Released: 2026-08-26
Deposition Author(s): Jiang, Y.J., Gao, Y.G.
Funding Organization(s): Ministry of Education (MoE, Singapore)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 5.00 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 24XX

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM Structure of a 12mer MucD cage

Jiang, Y.J., Gao, Y.G.

To be published.

Macromolecule Content

Total Structure Weight: 614.31 kDa
Atom Count: 35,016
Modeled Residue Count: 4,716
Deposited Residue Count: 5,760
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable periplasmic serine endoprotease DegP-like	A B C D [auth E] E [auth G] A, B, C, D [auth E], E [auth G], F [auth H], G [auth K], H [auth M], I [auth N], J [auth Q], K [auth S], L [auth T]	480	Pseudomonas aeruginosa PAO1	Mutation(s): 1 Gene Names: mucD, PA0766 EC: 3.4.21.107
UniProt
Find proteins for G3XD20 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore G3XD20 Go to UniProtKB: G3XD20
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	G3XD20
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 5.00 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-26

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Education (MoE, Singapore)	Singapore	--

Revision History (Full details and data files)

Version 1.0: 2026-08-26
Type: Initial release
