24GZ | pdb_000024gz

Artificial Copper-binding trimeric protein 1 (Cu(I)TP6)

PDB DOI: https://doi.org/10.2210/pdb24GZ/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Methanococcus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-03-03 Released: 2026-07-15
Deposition Author(s): Choi, I.S., Song, W.J.
Funding Organization(s): National Research Foundation (NRF, Korea)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.34 Å
R-Value Free:
0.267 (Depositor), 0.265 (DCC)
R-Value Work:
0.209 (Depositor), 0.207 (DCC)
R-Value Observed:
0.211 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 24GZ

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Artificial Copper-binding trimeric protein 1 (Cu(I)TP6)

Choi, I.S., Song, W.J.

To be published.

Macromolecule Content

Total Structure Weight: 85.82 kDa
Atom Count: 5,853
Modeled Residue Count: 700
Deposited Residue Count: 753
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphosulfolactate synthase	A, B, C	251	Methanococcus	Mutation(s): 0 Gene Names: comA, MJ0255 EC: 4.4.1.19
UniProt
Find proteins for Q57703 (Methanocaldococcus jannaschii (strain ATCC 43067 / DSM 2661 / JAL-1 / JCM 10045 / NBRC 100440)) Explore Q57703 Go to UniProtKB: Q57703
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q57703
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
TRS (Subject of Investigation/LOI) Query on TRS Download:Ideal Coordinates CCD File SDF format, chain E [auth B] MOL2 format, chain E [auth B] mmCIF format, chain E [auth B]	E [auth B]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain E [auth B] Interactions & Density Focus chain E [auth B]
CU1 (Subject of Investigation/LOI) Query on CU1 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain F [auth B] SDF format, chain G [auth C] MOL2 format, chain D [auth A] MOL2 format, chain F [auth B] MOL2 format, chain G [auth C] mmCIF format, chain D [auth A] mmCIF format, chain F [auth B] mmCIF format, chain G [auth C]	D [auth A], F [auth B], G [auth C]	COPPER (I) ION Cu VMQMZMRVKUZKQL-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain F [auth B] Focus chain G [auth C] Interactions & Density Focus chain D [auth A] Focus chain F [auth B] Focus chain G [auth C]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
BP5 Query on BP5	A, B, C	L-PEPTIDE LINKING	C₁₃ H₁₃ N₃ O₂		ALA

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.34 Å
R-Value Free: 0.267 (Depositor), 0.265 (DCC)
R-Value Work: 0.209 (Depositor), 0.207 (DCC)
R-Value Observed: 0.211 (Depositor)

Space Group: P 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 115.256	α = 90
b = 115.256	β = 90
c = 38.969	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-15

Deposition Author(s):

Funding Organization	Location	Grant Number
National Research Foundation (NRF, Korea)	Korea, Republic Of	--

Revision History (Full details and data files)

Version 1.0: 2026-07-15
Type: Initial release
