23AS | pdb_000023as

Structure of Arabidopsis SNX1 (Class l, 7-fold)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.20 Å
  • Aggregation State: HELICAL ARRAY
  • Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 23AS

This is version 1.1 of the entry. See complete history

Literature

SNX-mediated biogenesis of a plant-unique vesicle derived from the multivesicular body.

Li, Y.Tao, R.Zhang, H.Wen, X.Leung, S.K.P.Qi, Q.Zheng, X.Guo, H.Wu, C.Fu, Z.Huang, X.Lau, W.C.Y.Jiang, L.Cui, Y.

(2026) Nat Commun

  • DOI: https://doi.org/10.1038/s41467-026-71067-x
  • Primary Citation Related Structures:
    23AS, 23AT

  • PubMed Abstract:

    Retrograde transport is central to endomembrane homeostasis, yet the identity and origin of plant retrograde carriers remain unresolved. Prevailing models propose that plant vacuolar sorting receptors (VSRs) recycle either from multivesicular bodies (MVBs) to the trans-Golgi network (TGN) or from the TGN to the Golgi apparatus and/or endoplasmic reticulum (ER). However, the ultrastructural features of plant retrograde transport carriers remain largely unresolved. Here, we show that plant retrograde transport is likely mediated by a previously unrecognized class of MVB-derived spherical vesicles. Using correlative light and electron microscopy and three-dimensional electron tomography, we identify a distinct population of ~30-50 nm spherical vesicles adjacent to MVBs, including nascent vesicles budding from the MVB limiting membrane in Arabidopsis root cells. Immunogold labeling shows that these vesicles are enriched in retromer components and VSRs, suggesting that they possibly function as retrograde transport carriers. To investigate their biogenesis, we perform cryo-electron microscopy and liposome tubulation assays, showing that Arabidopsis SNX1 generates shorter membrane tubules than its mammalian counterpart, consistent with reduced membrane affinity linked to differences in the amphipathic helix. Notably, the SNX1-SNX2 heterodimer produces heterogeneous structures, including spherical vesicles, recapitulating in vivo observations. Lastly, knockdown of SNX1 or SNX2 results in vacuolar mislocalization and increased degradation of GFP-VSR2, and defects in SNX1 and VPS29 inhibit formation of spherical vesicles adjacent to MVBs, resulting in embryonic lethality before the globular stage. Together, these findings establish MVB-derived spherical vesicles as plant retrograde carriers and reveal a distinct SNX-mediated mechanism underlying their formation.


  • Organizational Affiliation
    • State Key Laboratory of Cellular Stress Biology, School of Life Sciences, Faculty of Medicine and Life Sciences, Xiamen University, Xiamen, China.

Macromolecule Content

  • Total Structure Weight: 3,774.12 kDa
  • Atom Count: 251,262
  • Modeled Residue Count: 30,699
  • Deposited Residue Count: 32,562
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Sorting nexin 1402Arabidopsis thalianaMutation(s): 0
Gene Names: SNX1VPS5At5g06140K16F4.11MBL20
UniProt
Find proteins for Q9FG38 (Arabidopsis thaliana)
Explore Q9FG38
Go to UniProtKB:  Q9FG38
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9FG38
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.20 Å
  • Aggregation State: HELICAL ARRAY
  • Reconstruction Method: HELICAL
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX2.0_5936
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32270727, 32000141
Other government2021J01029
Other government20720210094
The University Grants Committee, Research Grants Council (RGC)Hong KongCUHK14106823, C4033-19E, C4002-20W, C4002-21EF, C4014-23G, R4005-18, Senior Research Fellow Scheme SRFS2122-4S01 and CRS_CUHK405/23

Revision History  (Full details and data files)

  • Version 1.0: 2026-03-18
    Type: Initial release
  • Version 1.1: 2026-04-01
    Changes: Data collection, Database references
