22WM | pdb_000022wm

Phosphoglycerate mutase 1 complexed with a fragment

PDB DOI: https://doi.org/10.2210/pdb22WM/pdb

Classification: ISOMERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-01-26 Released: 2026-02-11
Deposition Author(s): Li, S., Zhou, L.
Funding Organization(s): Other government

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.91 Å
R-Value Free:
0.229 (Depositor), 0.229 (DCC)
R-Value Work:
0.197 (Depositor), 0.196 (DCC)
R-Value Observed:
0.198 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Phosphoglycerate mutase 1 complexed with a fragment

Li, S., Zhou, L.

To be published.

Macromolecule Content

Total Structure Weight: 61.45 kDa
Atom Count: 4,119
Modeled Residue Count: 477
Deposited Residue Count: 524
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphoglycerate mutase 1	A [auth B], B [auth C]	262	Homo sapiens	Mutation(s): 0 Gene Names: PGAM1, PGAMA, CDABP0006 EC: 5.4.2.11 (PDB Primary Data), 5.4.2.4 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P18669 (Homo sapiens) Explore P18669 Go to UniProtKB: P18669
PHAROS: P18669 GTEx: ENSG00000171314
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P18669
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1E4R (Subject of Investigation/LOI) Query on A1E4R Download Ideal Coordinates CCD File SDF format, chain C [auth B] SDF format, chain L [auth C] MOL2 format, chain C [auth B] MOL2 format, chain L [auth C] mmCIF format, chain C [auth B] mmCIF format, chain L [auth C]	C [auth B], L [auth C]	4-(4-chlorophenyl)benzoic acid C₁₃ H₉ Cl O₂ FIMRRWLTRBEAOM-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain L [auth C] Interactions & Density Focus chain C [auth B] Focus chain L [auth C]
MES Query on MES Download Ideal Coordinates CCD File SDF format, chain M [auth C] MOL2 format, chain M [auth C] mmCIF format, chain M [auth C]	M [auth C]	2-(N-MORPHOLINO)-ETHANESULFONIC ACID C₆ H₁₃ N O₄ S SXGZJKUKBWWHRA-UHFFFAOYSA-N		Interactions Focus chain M [auth C] Interactions & Density Focus chain M [auth C]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain E [auth B] SDF format, chain G [auth B] SDF format, chain H [auth B] SDF format, chain I [auth B] SDF format, chain J [auth B] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain P [auth C] SDF format, chain F [auth B] MOL2 format, chain D [auth B] MOL2 format, chain E [auth B] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain P [auth C] MOL2 format, chain F [auth B] mmCIF format, chain D [auth B] mmCIF format, chain E [auth B] mmCIF format, chain G [auth B] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain P [auth C] mmCIF format, chain F [auth B]	D [auth B] E [auth B] F [auth B] G [auth B] H [auth B] D [auth B], E [auth B], F [auth B], G [auth B], H [auth B], I [auth B], J [auth B], N [auth C], O [auth C], P [auth C]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C] Interactions & Density Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain N [auth C] Focus chain O [auth C] Focus chain P [auth C]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain K [auth B] MOL2 format, chain K [auth B] mmCIF format, chain K [auth B]	K [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain K [auth B] Interactions & Density Focus chain K [auth B]
