1ZYK

Anthranilate Phosphoribosyltransferase in complex with PRPP, anthranilate and magnesium


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.207

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.0 of the entry. See complete history


Literature

Structural and mutational analysis of substrate complexation by anthranilate phosphoribosyltransferase from Sulfolobus solfataricus.

Marino, M.Deuss, M.Svergun, D.I.Konarev, P.V.Sterner, R.Mayans, O.

(2006) J Biol Chem 281: 21410-21421

  • DOI: https://doi.org/10.1074/jbc.M601403200
  • Primary Citation of Related Structures:
    1ZXY, 1ZYK, 2GVQ

  • PubMed Abstract:

    The metabolic synthesis and degradation of essential nucleotide compounds are primarily carried out by phosphoribosyltransferases (PRT) and nucleoside phosphorylases (NP), respectively. Despite the resemblance of their reactions, five classes of PRTs and NPs exist, where anthranilate PRT (AnPRT) constitutes the only evolutionary link between synthesis and degradation processes. We have characterized the active site of dimeric AnPRT from Sulfolobus solfataricus by elucidating crystal structures of the wild-type enzyme complexed to its two natural substrates anthranilate and 5-phosphoribosyl-1-pyrophosphate/Mg(2+). These bind into two different domains within each protomer and are brought together during catalysis by rotational domain motions as shown by small angle x-ray scattering data. Steady-state kinetics of mutated AnPRT variants address the role of active site residues in binding and catalysis. Results allow the comparative analysis of PRT and pyrimidine NP families and expose related structural motifs involved in nucleotide/nucleoside recognition by these enzyme families.


  • Organizational Affiliation

    Division of Structural Biology, Biozentrum, University of Basel, Klingelbergstrasse 70, CH-4056 Basel, Switzerland.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Anthranilate phosphoribosyltransferase
A, B, C, D
345Saccharolobus solfataricusMutation(s): 0
EC: 2.4.2.18
UniProt
Find proteins for P50384 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2))
Explore P50384
Go to UniProtKB:  P50384
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP50384
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PRP
Query on PRP

Download Ideal Coordinates CCD File
G [auth A],
L [auth B],
Q [auth C],
V [auth D]
1-O-pyrophosphono-5-O-phosphono-alpha-D-ribofuranose
C5 H13 O14 P3
PQGCEDQWHSBAJP-TXICZTDVSA-N
BE2
Query on BE2

Download Ideal Coordinates CCD File
H [auth A]
I [auth A]
M [auth B]
N [auth B]
R [auth C]
H [auth A],
I [auth A],
M [auth B],
N [auth B],
R [auth C],
S [auth C],
W [auth D],
X [auth D]
2-AMINOBENZOIC ACID
C7 H7 N O2
RWZYAGGXGHYGMB-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
J [auth B]
K [auth B]
O [auth C]
E [auth A],
F [auth A],
J [auth B],
K [auth B],
O [auth C],
P [auth C],
T [auth D],
U [auth D]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free: 0.269
  • R-Value Work: 0.207
  • Space Group: P 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.556α = 90
b = 66.099β = 107.76
c = 117.069γ = 90
Software Package:
Software NamePurpose
XDSdata scaling
XDSdata reduction
CNSrefinement
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-05-23
    Type: Initial release
  • Version 1.1: 2008-04-30
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Data collection, Derived calculations, Structure summary
  • Version 1.4: 2023-08-23
    Changes: Data collection, Database references, Refinement description, Structure summary
  • Version 2.0: 2023-11-15
    Changes: Atomic model, Data collection
