1ZEJ | pdb_00001zej

Crystal structure of the 3-hydroxyacyl-coa dehydrogenase (hbd-9, af2017) from archaeoglobus fulgidus dsm 4304 at 2.00 A resolution

• PDB DOI: https://doi.org/10.2210/pdb1ZEJ/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Archaeoglobus fulgidus DSM 4304
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2005-04-18 Released: 2005-05-03
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:
  0.221 (Depositor), 0.225 (DCC)
• R-Value Work:
  0.179 (Depositor), 0.181 (DCC)
• R-Value Observed:
  0.181 (Depositor)

Literature

Crystal structure of 3-hydroxyacyl-CoA dehydrogenase (HBD-9) (np_070841.1) from Archaeoglobus fulgidus at 2.00 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA,PQS (software)

Macromolecule Content

• Total Structure Weight: 33.94 kDa
• Atom Count: 2,406
• Modeled Residue Count: 282
• Deposited Residue Count: 293
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3-hydroxyacyl-CoA dehydrogenase	A	293	Archaeoglobus fulgidus DSM 4304	Mutation(s): 6  Gene Names: hbd-9 EC: 1.1.1.35 (PDB Primary Data), 1.1.1.45 (UniProt)
UniProt
Find proteins for O28262 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16)) Explore O28262  Go to UniProtKB:  O28262

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PE8	C [auth A]	3,6,9,12,15,18,21-HEPTAOXATRICOSANE-1,23-DIOL C16 H34 O9 GLZWNFNQMJAZGY-UHFFFAOYSA-N
CL	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.00 Å
• R-Value Free:  0.221 (Depositor), 0.225 (DCC)
• R-Value Work:  0.179 (Depositor), 0.181 (DCC)
• R-Value Observed: 0.181 (Depositor)

Diffraction Data: https://doi.org/10.18430/M31ZEJ

Space Group: P 6 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 146.331	α = 90
b = 146.331	β = 90
c = 62.73	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
CCP4	data scaling
SOLVE	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-05-03
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2005-05-03
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Derived calculations, Source and taxonomy, Version format compliance
• Version 1.3: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.4: 2024-11-13
  Changes: Data collection, Structure summary
