1WO8 | pdb_00001wo8

Crystal structure of methylglyoxal synthase from Thermus thermophilus HB8

• PDB DOI: https://doi.org/10.2210/pdb1WO8/pdb

• Classification: LYASE
• Organism(s): Thermus thermophilus HB8
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2004-08-12 Released: 2005-08-23
• Deposition Author(s): Sugahara, M., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:
  0.204 (Depositor), 0.205 (DCC)
• R-Value Work:
  0.185 (Depositor), 0.185 (DCC)
• R-Value Observed:
  0.186 (Depositor)

Literature

Crystal structure of methylglyoxal synthase from Thermus thermophilus HB8

Sugahara, M., Kunishima, N.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D3  (Explore in 3D)
Global Stoichiometry: Homo 6-mer - A6

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 12-mer - A12

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 81.06 kDa
• Atom Count: 6,357
• Modeled Residue Count: 740
• Deposited Residue Count: 756
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
methylglyoxal synthase	A, B, C, D, E, F	126	Thermus thermophilus HB8	Mutation(s): 0  EC: 4.2.3.3
UniProt
Find proteins for Q5SHD6 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SHD6  Go to UniProtKB:  Q5SHD6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	G [auth A], H [auth B], I [auth C], J [auth D], K [auth D], L [auth E], M [auth F]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:  0.204 (Depositor), 0.205 (DCC)
• R-Value Work:  0.185 (Depositor), 0.185 (DCC)
• R-Value Observed: 0.186 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 130.612	α = 90
b = 130.612	β = 90
c = 96.653	γ = 120

Software Package:

Software Name	Purpose
HKL-2000	data collection
SCALEPACK	data scaling
SOLVE	phasing
CNS	refinement
HKL-2000	data reduction

Structure Validation

Entry History

Deposition Data

• Released Date: 2005-08-23
Deposition Author(s): Sugahara, M., Kunishima, N., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2005-08-23
  Type: Initial release

• Version 1.1: 2008-04-30
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Version format compliance
• Version 1.3: 2024-03-13
  Changes: Data collection, Database references, Derived calculations
