1W68

Crystal Structure of Mouse Ribonucleotide Reductase Subunit R2 under Oxidizing Conditions. A Fully Occupied Dinuclear Iron Cluster.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.214
  • R-Value Observed: 0.214

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Crystal Structural Studies of Changes in the Native Dinuclear Iron Center of Ribonucleotide Reductase Protein R2 from Mouse

Strand, K.R.Karlsen, S.Kolberg, M.Rohr, A.K.Gorbitz, C.H.Andersson, K.K.

(2004) J Biol Chem 279: 46794

  • DOI: https://doi.org/10.1074/jbc.M407346200
  • Primary Citation of Related Structures:
    1W68, 1W69

  • PubMed Abstract:

    Class I ribonucleotide reductase (RNR) catalyzes the de novo synthesis of deoxyribonucleotides in mammals and many other organisms. The RNR subunit R2 contains a dinuclear iron center, which in its diferrous form spontaneously reacts with O2, forming a mu-oxo-bridged diferric cluster and a stable tyrosyl radical. Here, we present the first crystal structures of R2 from mouse with its native dinuclear iron center, both under reducing and oxidizing conditions. In one structure obtained under reducing conditions, the iron-bridging ligand Glu-267 adopts the mu-(eta1,eta2) coordination mode, which has previously been related to O2 activation, and an acetate ion from the soaking solution is observed where O2 has been proposed to bind the iron. The structure of mouse R2 under oxidizing conditions resembles the nonradical diferric R2 from Escherichia coli, with the exception of the coordination of water and Asp-139 to Fe1. There are also additional water molecules near the tyrosyl radical site, as suggested by previous spectroscopic studies. Since no crystal structure of the active radical form has been reported, we propose models for the movement of waters and/or tyrosyl radical site when diferric R2 is oxidized to the radical form, in agreement with our previous ENDOR study. Compared with E. coli R2, two conserved phenylalanine residues in the hydrophobic environment around the diiron center have opposing rotameric conformations, and the carboxylate ligands of the diiron center in mouse R2 appear more flexible. Together, this might contribute to the lower affinity and cooperative binding of iron in mouse R2.


  • Organizational Affiliation

    Department of Molecular Biosciences, University of Oslo, PO Box 1041 Blindern, Oslo NO-0316, Norway.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RIBONUCLEOSIDE-DIPHOSPHATE REDUCTASE M2 CHAIN390Mus musculusMutation(s): 0
EC: 1.17.4.1
UniProt & NIH Common Fund Data Resources
Find proteins for P11157 (Mus musculus)
Explore P11157
Go to UniProtKB:  P11157
IMPC:  MGI:98181
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP11157
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FEO
Query on FEO

Download Ideal Coordinates CCD File
B [auth A]MU-OXO-DIIRON
Fe2 O
NPMYUMBHPJGBFA-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.214
  • R-Value Observed: 0.214
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 75.291α = 90
b = 106.523β = 90
c = 91.791γ = 90
Software Package:
Software NamePurpose
CNSrefinement
DENZOdata reduction
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-08-26
    Type: Initial release
  • Version 1.1: 2011-05-08
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
