1VLL | pdb_00001vll

Crystal structure of alanine dehydrogenase (AF1665) from Archaeoglobus fulgidus at 2.80 A resolution

PDB DOI: https://doi.org/10.2210/pdb1VLL/pdb

Classification: OXIDOREDUCTASE
Organism(s): Archaeoglobus fulgidus DSM 4304
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2004-08-03 Released: 2004-09-21
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free:
0.254 (Depositor), 0.256 (DCC)
R-Value Work:
0.217 (Depositor), 0.216 (DCC)
R-Value Observed:
0.219 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1VLL

This is version 1.4 of the entry. See complete history.

Literature

Crystal structure of alanine dehydrogenase (AF1665) from Archaeoglobus fulgidus at 2.80 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 72.66 kDa
Atom Count: 4,574
Modeled Residue Count: 642
Deposited Residue Count: 668
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
alanine dehydrogenase	A, B	334	Archaeoglobus fulgidus DSM 4304	Mutation(s): 0 Gene Names: AF1665, arcB EC: 1.4.1.1
UniProt
Find proteins for O28608 (Archaeoglobus fulgidus (strain ATCC 49558 / DSM 4304 / JCM 9628 / NBRC 100126 / VC-16)) Explore O28608 Go to UniProtKB: O28608
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O28608
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.80 Å
R-Value Free: 0.254 (Depositor), 0.256 (DCC)
R-Value Work: 0.217 (Depositor), 0.216 (DCC)
R-Value Observed: 0.219 (Depositor)

Diffraction Data:

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.702	α = 90
b = 92.437	β = 90
c = 131.783	γ = 90

Software Package:

Software Name	Purpose
MOSFLM	data reduction
SCALA	data scaling
SOLVE	phasing
RESOLVE	model building
REFMAC	refinement
CCP4	data scaling
RESOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2004-09-21

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2004-09-21
Type: Initial release
Version 1.1: 2008-04-26
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Source and taxonomy, Version format compliance
Version 1.3: 2023-01-25
Changes: Database references
Version 1.4: 2024-05-22
Changes: Data collection, Refinement description
