1UVT

BOVINE THROMBIN--BM14.1248 COMPLEX


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work: 0.214
  • R-Value Observed: 0.214

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Enzyme flexibility, solvent and 'weak' interactions characterize thrombin-ligand interactions: implications for drug design.

Engh, R.A.Brandstetter, H.Sucher, G.Eichinger, A.Baumann, U.Bode, W.Huber, R.Poll, T.Rudolph, R.von der Saal, W.

(1996) Structure 4: 1353-1362

  • DOI: https://doi.org/10.1016/s0969-2126(96)00142-6
  • Primary Citation of Related Structures:
    1UVS, 1UVT, 1UVU

  • PubMed Abstract:

    The explosive growth in the rate of X-ray determination of protein structures is fuelled largely by the expectation that structural information will be useful for pharmacological and biotechnological applications. For example, there have been intensive efforts to develop orally administrable antithrombotic drugs using information about the crystal structures of blood coagulation factors, including thrombin. Most of the low molecular weight thrombin inhibitors studied so far are based on arginine and benzamidine. We sought to expand the database of information on thrombin-inhibitor binding by studying new classes of inhibitors. We report the structures of three new inhibitors complexed with thrombin, two based on 4-aminopyridine and one based on naphthamidine. We observe several geometry changes in the protein main chain and side chains which accompany inhibitor binding. The two inhibitors based on 4-aminopyridine bind in notably different ways: one forms a water-mediated hydrogen bond to the active site Ser195, the other induces a rotation of the Ser214-Trp215 peptide plane that is unprecedented in thrombin structures. These binding modes also differ in their 'weak' interactions, including CH-O hydrogen bonds and interactions between water molecules and aromatic pi-clouds. Induced-fit structural changes were also seen in the structure of the naphthamidine inhibitor complex. Protein flexibility and variable water structures are essential elements in protein-ligand interactions. Ligand design strategies that fail to take this into account may overlook or underestimate the potential of lead structures. Further, the significance of 'weak' interactions must be considered both in crystallographic refinement and in analysis of binding mechanisms.


  • Organizational Affiliation

    Max-Planck-Institut für Biochemie, D82152 Martinsried, Germany. engh@biochem.mpg.de


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
THROMBINA [auth L]49Bos taurusMutation(s): 0
EC: 3.4.21.5
UniProt
Find proteins for P00735 (Bos taurus)
Explore P00735
Go to UniProtKB:  P00735
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00735
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
THROMBINB [auth H]259Bos taurusMutation(s): 0
EC: 3.4.21.5
UniProt
Find proteins for P00735 (Bos taurus)
Explore P00735
Go to UniProtKB:  P00735
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00735
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
I48
Query on I48

Download Ideal Coordinates CCD File
C [auth H]N-{3-METHYL-5-[2-(PYRIDIN-4-YLAMINO)-ETHOXY]-PHENYL}-BENZENESULFONAMIDE
C20 H22 N3 O3 S
MPTWCWHNLVMCRW-UHFFFAOYSA-O
Binding Affinity Annotations
IDSourceBinding Affinity
I48 PDBBind:  1UVT Ki: 23 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.50 Å
  • R-Value Work: 0.214
  • R-Value Observed: 0.214
  • Space Group: P 42 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 87.5α = 90
b = 87.5β = 90
c = 103.2γ = 90
Software Package:
Software NamePurpose
X-PLORmodel building
X-PLORrefinement
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1997-11-19
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-06-05
    Changes: Data collection, Database references, Derived calculations, Other
  • Version 1.4: 2024-10-30
    Changes: Structure summary
