1U5F | pdb_00001u5f

Crystal Structure of the PH Domain of SKAP-Hom with 8 Vector-derived N-terminal Residues

PDB DOI: https://doi.org/10.2210/pdb1U5F/pdb

Classification: SIGNALING PROTEIN
Organism(s): Mus musculus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2004-07-27 Released: 2005-07-26
Deposition Author(s): Tang, Y., Swanson, K.D., Neel, B.G., Eck, M.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.246 (Depositor), 0.249 (DCC)
R-Value Work:
0.226 (Depositor), 0.221 (DCC)
R-Value Observed:
0.227 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1U5F

This is version 1.4 of the entry. See complete history.

Literature

Structural Basis for the Dimerization and Phosphoinositide Specificity of the Src Kinase-associated Phosphoproteins SKAP55 and SKAP-Hom

Tang, Y., Swanson, K.D., Neel, B.G., Eck, M.J.

To be published.

Macromolecule Content

Total Structure Weight: 17.2 kDa
Atom Count: 995
Modeled Residue Count: 119
Deposited Residue Count: 148
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Src-associated adaptor protein	A	148	Mus musculus	Mutation(s): 1 Gene Names: SCAP2
UniProt
Find proteins for Q3UND0 (Mus musculus) Explore Q3UND0 Go to UniProtKB: Q3UND0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q3UND0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.246 (Depositor), 0.249 (DCC)
R-Value Work: 0.226 (Depositor), 0.221 (DCC)
R-Value Observed: 0.227 (Depositor)

Space Group: H 3 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.75	α = 90
b = 78.75	β = 90
c = 130.123	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
DENZO	data reduction
SCALEPACK	data scaling
MLPHARE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2005-07-26

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2005-07-26
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Derived calculations, Version format compliance
Version 1.3: 2021-10-20
Changes: Database references, Derived calculations
Version 1.4: 2024-02-14
Changes: Data collection
