1SYF

ENGINEERING ALTERNATIVE BETA-TURN TYPES IN STAPHYLOCOCCAL NUCLEASE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Observed: 0.168

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Engineering alternative beta-turn types in staphylococcal nuclease.

Hynes, T.R.Hodel, A.Fox, R.O.

(1994) Biochemistry 33: 5021-5030

  • DOI: https://doi.org/10.1021/bi00183a004
  • Primary Citation of Related Structures:
    1SYC, 1SYD, 1SYE, 1SYF, 1SYG

  • PubMed Abstract:

    We have refined the crystal structures of three point mutants of staphylococcal nuclease designed to favor alternative beta-turn types. Single amino acid substitutions were made in a type VIa beta-turn (residues 115-118; Tyr-Lys-Pro-Asn) containing a cis Lys 116-Pro 117 peptide bond. The mutations result in two new backbone conformations, a type I beta-turn for P117T and a type I' beta-turn for P117G and P117A. The P117G and P117A structures exhibit a dramatic difference in backbone conformation in the region of the mutation compared to the nuclease A structure such that the side chain of Lys 116 is reoriented to point into the nucleotide binding pocket. The distinct conformation observed for the nuclease A, P117G, and P117T beta-turn sequences agrees with correlations between beta-turn type and sequence identified from protein crystal structures. The P117A turn conformation provides an exception to these correlations. The results demonstrate that single residue changes can significantly alter backbone conformation, illustrating the process by which diversity in the structure of the protein surface can evolve on a conserved structural core, and suggest protein engineering applications in which the positioning as well as the identify of side chains can be modified to design new enzyme functions. Nuclease variants at the type VIa beta-turn site also allow the relationship between the amino acid sequence and beta-turn conformation to be examined in the context of an identical protein fold in crystallographic detail.


  • Organizational Affiliation

    Department of Molecular Biophysics and Biochemistry, Yale University, New Haven, Connecticut 06520.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
STAPHYLOCOCCAL NUCLEASE149Staphylococcus aureusMutation(s): 0
EC: 3.1.31.1
UniProt
Find proteins for P00644 (Staphylococcus aureus)
Explore P00644
Go to UniProtKB:  P00644
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00644
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
THP
Query on THP

Download Ideal Coordinates CCD File
C [auth A]THYMIDINE-3',5'-DIPHOSPHATE
C10 H16 N2 O11 P2
CSNCBOPUCJOHLS-XLPZGREQSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
B [auth A]CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Observed: 0.168
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.5α = 90
b = 48.5β = 90
c = 63.5γ = 90
Software Package:
Software NamePurpose
PROLSQrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 1994-07-31
    Type: Initial release
  • Version 1.1: 2008-03-24
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2017-11-29
    Changes: Derived calculations, Other
  • Version 1.4: 2024-02-14
    Changes: Data collection, Database references, Derived calculations
