1K9B | pdb_00001k9b

Crystal structure of the bifunctional soybean Bowman-Birk inhibitor at 0.28 nm resolution. Structural peculiarities in a folded protein conformation


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:
    0.308 (Depositor)
  • R-Value Work:
    0.221 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 1K9B

This is version 1.4 of the entry. See complete history

Literature

Crystal structure of the bifunctional soybean Bowman-Birk inhibitor at 0.28-nm resolution. Structural peculiarities in a folded protein conformation.

Voss, R.H.Ermler, U.Essen, L.O.Wenzl, G.Kim, Y.M.Flecker, P.

(1996) Eur J Biochem 242: 122-131

  • DOI: https://doi.org/10.1111/j.1432-1033.1996.0122r.x
  • Primary Citation Related Structures:
    1K9B

  • PubMed Abstract:

    The Bowman-Birk inhibitor from soybean is a small protein that contains a binary arrangement of trypsin-reactive and chymotrypsin-reactive subdomains. In this report, the crystal structure of this anticarcinogenic protein has been determined to 0.28-nm resolution by molecular replacement from crystals grown at neutral pH. The crystal structure differs from a previously determined NMR structure [Werner, M. H. & Wemmer, D. E. (1992) Biochemistry 31, 999-1010] in the relative orientation of the two enzyme-insertion loops, in some details of the main chain trace, in the presence of favourable contacts in the trypsin-insertion loop, and in the orientation of several amino acid side chains. The proximity of Met27 and Gln48 in the X-ray structure contradicts the solution structure, in which these two side chains point away from each other. The significant effect of a Met27-->Ile replacement on the inhibitory activity of the chymotrypsin-reactive subdomain agrees with the X-ray structure. Exposed hydrophobic patches, the presence of charged amino acid residues, and the presence of water molecules in the protein interior are in contrast to standard proteins that comprise a hydrophobic core and exposed polar amino acids.


  • Organizational Affiliation
    • Max-Planck-Institut für Biophysik, Frankfurt am Main, Germany.

Macromolecule Content

  • Total Structure Weight: 6.43 kDa
  • Atom Count: 437
  • Modeled Residue Count: 58
  • Deposited Residue Count: 58
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
BOWMAN-BIRK TYPE PROTEINASE INHIBITOR58Glycine maxMutation(s): 0
UniProt
Find proteins for P01055 (Glycine max)
Explore P01055
Go to UniProtKB:  P01055
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP01055
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free:  0.308 (Depositor)
  • R-Value Work:  0.221 (Depositor)
Space Group: P 41 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.1α = 90
b = 86.1β = 90
c = 86.1γ = 90
Software Package:
Software NamePurpose
WEISdata scaling
ROTAVATAdata reduction
X-PLORmodel building
X-PLORrefinement
WEISdata reduction
CCP4data scaling
ROTAVATAdata scaling
X-PLORphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-11-16
    Type: Initial release
  • Version 1.1: 2007-10-21
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-16
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2024-10-30
    Changes: Structure summary
