1J7G | pdb_00001j7g

Structure of YihZ from Haemophilus influenzae (HI0670), a D-Tyr-tRNA(Tyr) deacylase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free:
    0.220 (Depositor), 0.223 (DCC)
  • R-Value Work:
    0.194 (Depositor), 0.195 (DCC)

wwPDB Validation 3D Report Full Report

Validation slider image for 1J7G

This is version 1.3 of the entry. See complete history

Literature

A Catalytic Mechanism for D-Tyr-tRNATyr Deacylase Based on the Crystal Structure of Hemophilus influenzae HI0670

Lim, K.Tempczyk, A.Bonander, N.Toedt, J.Howard, A.Einsenstein, E.Herzberg, O.

(2003) J Biological Chem 278: 13496-13502

  • DOI: https://doi.org/10.1074/jbc.M213150200
  • Primary Citation Related Structures:
    1J7G

  • PubMed Abstract:

    D-Tyr-tRNA(Tyr) deacylase is an editing enzyme that removes d-tyrosine and other d-amino acids from charged tRNAs, thereby preventing incorrect incorporation of d-amino acids into proteins. A model for the catalytic mechanism of this enzyme is proposed based on the crystal structure of the enzyme from Haemophilus influenzae determined at a 1.64-A resolution. Structural comparison of this dimeric enzyme with the very similar structure of the enzyme from Escherichia coli together with sequence analyses indicate that the active site is located in the dimer interface within a depression that includes an invariant threonine residue, Thr-80. The active site contains an oxyanion hole formed by the main chain nitrogen atoms of Thr-80 and Phe-79 and the side chain amide group of the invariant Gln-78. The Michaelis complex between the enzyme and D-Tyr-tRNA was modeled assuming a nucleophilic attack on the carbonyl carbon of D-Tyr by the Thr-80 O(gamma) atom and a role for the oxyanion hole in stabilizing the negatively charged tetrahedral transition states. The model is consistent with all of the available data on substrate specificity. Based on this model, we propose a substrate-assisted acylation/deacylation-catalytic mechanism in which the amino group of the D-Tyr is deprotonated and serves as the general base.


  • Organizational Affiliation
    • Center for Advanced Research In Biotechnology, University of Maryland Biotechnology Institute, Rockville, Maryland 20850, USA.

Macromolecule Content

  • Total Structure Weight: 15.88 kDa
  • Atom Count: 1,322
  • Modeled Residue Count: 144
  • Deposited Residue Count: 144
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
D-tyrosyl-tRNA(Tyr) deacylase144Haemophilus influenzae Rd KW20Mutation(s): 0
Gene Names: HI0670
EC: 3.1 (PDB Primary Data), 3.1.1.96 (UniProt)
UniProt
Find proteins for P44814 (Haemophilus influenzae (strain ATCC 51907 / DSM 11121 / KW20 / Rd))
Explore P44814
Go to UniProtKB:  P44814
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP44814
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.64 Å
  • R-Value Free:  0.220 (Depositor), 0.223 (DCC)
  • R-Value Work:  0.194 (Depositor), 0.195 (DCC)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.47α = 90
b = 55.47β = 90
c = 128.75γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
SOLVEphasing
MLPHAREphasing
DMmodel building
CNSrefinement
DMphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2003-04-22
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Derived calculations, Version format compliance
  • Version 1.3: 2024-02-07
    Changes: Data collection, Database references
