13BD | pdb_000013bd

Local refinement of the RBD and NTD in the closed BA.3.2.1 spike with N529Q mutant

PDB DOI: https://doi.org/10.2210/pdb13BD/pdb
EM Map EMD-76936: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2026-04-27 Released: 2026-06-17
Deposition Author(s): Wang, Y., Hu, Y., Xie, X.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.65 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 13BD

This is version 1.0 of the entry. See complete history.

Literature

Functional and Structural Basis of Omicron BA.3.2.1 Spike

Wang, Y., Hu, Y., Chen, Z., Zou, J., Zhang, K., Ren, P., Shi, P.Y., Liang, B., Xie, X.

To be published.

Macromolecule Content

Total Structure Weight: 284.25 kDa
Atom Count: 3,825
Modeled Residue Count: 461
Deposited Residue Count: 2,542
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
BA.3.2.2 Spike with N529Q mutation	A [auth C], B [auth A]	1,271	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C [auth B]	2		N-Glycosylation	Interactions Focus chain C [auth B] Interactions & Density Focus chain C [auth B]

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain E [auth C] SDF format, chain I [auth A] SDF format, chain H [auth C] SDF format, chain G [auth C] SDF format, chain F [auth C] SDF format, chain D [auth C] MOL2 format, chain E [auth C] MOL2 format, chain I [auth A] MOL2 format, chain H [auth C] MOL2 format, chain G [auth C] MOL2 format, chain F [auth C] MOL2 format, chain D [auth C] mmCIF format, chain E [auth C] mmCIF format, chain I [auth A] mmCIF format, chain H [auth C] mmCIF format, chain G [auth C] mmCIF format, chain F [auth C] mmCIF format, chain D [auth C]	D [auth C] E [auth C] F [auth C] G [auth C] H [auth C] D [auth C], E [auth C], F [auth C], G [auth C], H [auth C], I [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain D [auth C] Focus chain E [auth C] Focus chain F [auth C] Focus chain G [auth C] Focus chain H [auth C] Focus chain I [auth A] Interactions & Density Focus chain D [auth C] Focus chain E [auth C] Focus chain F [auth C] Focus chain G [auth C] Focus chain H [auth C] Focus chain I [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.65 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-06-17

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-06-17
Type: Initial release
