11WO | pdb_000011wo

SpACSA with AMPCPP, conformation 1

PDB DOI: https://doi.org/10.2210/pdb11WO/pdb
EM Map EMD-76137: EMDB EMDataResource

Classification: LIGASE
Organism(s): Schizosaccharomyces pombe
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-03-16 Released: 2026-07-22
Deposition Author(s): Li, M., Zhou, M., Marmorstein, R.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 11WO

This is version 1.0 of the entry. See complete history.

Literature

Ligand-Dependent Interdomain Rearrangements Drive Catalysis by Acetyl-CoA Synthetases

Li, M., Zhou, M., Marmorstein, R.

To be published.

Macromolecule Content

Total Structure Weight: 75.47 kDa
Atom Count: 5,138
Modeled Residue Count: 657
Deposited Residue Count: 676
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Acetyl-coenzyme A synthetase	A	676	Schizosaccharomyces pombe	Mutation(s): 0 Gene Names: SPCC191.02c, SPCC417.14c EC: 6.2.1.1
UniProt
Find proteins for P78773 (Schizosaccharomyces pombe (strain 972 / ATCC 24843)) Explore P78773 Go to UniProtKB: P78773
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P78773
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
APC (Subject of Investigation/LOI) Query on APC Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	DIPHOSPHOMETHYLPHOSPHONIC ACID ADENOSYL ESTER C₁₁ H₁₈ N₅ O₁₂ P₃ CAWZRIXWFRFUQB-IOSLPCCCSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.30 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-22

Deposition Author(s):

Marmorstein, R.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-07-22
Type: Initial release
