11GX | pdb_000011gx

E.Coli DNA Topoisomerase 3 in complex with an 8mer ssDNA oligo CGCAACTT

• PDB DOI: https://doi.org/10.2210/pdb11GX/pdb
• NAKB: 11GX

• Classification: ISOMERASE/DNA
• Organism(s): Escherichia coli, synthetic construct
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2026-02-23 Released: 2026-04-29
• Deposition Author(s): Tan, K., Tse Dinh, Y.C.
• Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.22 Å
• R-Value Free:
  0.261 (Depositor), 0.257 (DCC)
• R-Value Work:
  0.221 (Depositor), 0.221 (DCC)
• R-Value Observed:
  0.222 (Depositor)

Starting Model: experimental

Literature

E.Coli DNA Topoisomerase 3 in complex with an 8mer ssDNA oligo CGCAACTT

Tan, K., Tse Dinh, Y.C.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 75.72 kDa
• Atom Count: 5,143
• Modeled Residue Count: 628
• Deposited Residue Count: 654
• Unique protein chains: 1
• Unique nucleic acid chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA topoisomerase 3	A	646	Escherichia coli	Mutation(s): 0  Gene Names: topB, b1763, JW1752 EC: 5.6.2.1
UniProt
Find proteins for P14294 (Escherichia coli (strain K12)) Explore P14294  Go to UniProtKB:  P14294

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*CP*GP*CP*AP*AP*CP*TP*T)-3')	B	8	synthetic construct

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	C [auth A], D [auth A], E [auth A], F [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.22 Å
• R-Value Free:  0.261 (Depositor), 0.257 (DCC)
• R-Value Work:  0.221 (Depositor), 0.221 (DCC)
• R-Value Observed: 0.222 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 111.385	α = 90
b = 132.52	β = 133.962
c = 77.321	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
xia2	data scaling
PHENIX	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-04-29
Deposition Author(s): Tan, K., Tse Dinh, Y.C.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35GM139817

Revision History

• Version 1.0: 2026-04-29
  Type: Initial release
