11EG | pdb_000011eg

Crystal Structure of L-erythrulose-1-phosphate isomerase from Brucella melitensis (P1 form)

PDB DOI: https://doi.org/10.2210/pdb11EG/pdb

Classification: ISOMERASE
Organism(s): Brucella abortus 2308
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2026-02-18 Released: 2026-03-04
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.183 (Depositor), 0.193 (DCC)
R-Value Work:
0.155 (Depositor), 0.166 (DCC)
R-Value Observed:
0.157 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of L-erythrulose-1-phosphate isomerase from Brucella melitensis (P1 form)

Liu, L., Lovell, S., Battaile, K.P.

To be published.

Macromolecule Content

Total Structure Weight: 115.42 kDa
Atom Count: 8,783
Modeled Residue Count: 985
Deposited Residue Count: 1,048
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
L-erythrulose-1-phosphate isomerase	A, B, C, D	262	Brucella abortus 2308	Mutation(s): 1 Gene Names: eryH, tpiA-2, BAB2_0367 EC: 5.3.1.33
UniProt
Find proteins for Q2YIQ6 (Brucella abortus (strain 2308)) Explore Q2YIQ6 Go to UniProtKB: Q2YIQ6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q2YIQ6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain H [auth A] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain M [auth C] SDF format, chain P [auth D] SDF format, chain Q [auth D] SDF format, chain N [auth C] SDF format, chain G [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain H [auth A] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain M [auth C] MOL2 format, chain P [auth D] MOL2 format, chain Q [auth D] MOL2 format, chain N [auth C] MOL2 format, chain G [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain H [auth A] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain M [auth C] mmCIF format, chain P [auth D] mmCIF format, chain Q [auth D] mmCIF format, chain N [auth C] mmCIF format, chain G [auth A]	E [auth A] F [auth A] G [auth A] H [auth A] J [auth B] E [auth A], F [auth A], G [auth A], H [auth A], J [auth B], K [auth B], M [auth C], N [auth C], P [auth D], Q [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain M [auth C] Focus chain N [auth C] Focus chain P [auth D] Focus chain Q [auth D]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain L [auth B] SDF format, chain O [auth C] SDF format, chain R [auth D] MOL2 format, chain I [auth A] MOL2 format, chain L [auth B] MOL2 format, chain O [auth C] MOL2 format, chain R [auth D] mmCIF format, chain I [auth A] mmCIF format, chain L [auth B] mmCIF format, chain O [auth C] mmCIF format, chain R [auth D]	I [auth A], L [auth B], O [auth C], R [auth D]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain L [auth B] Focus chain O [auth C] Focus chain R [auth D] Interactions & Density Focus chain I [auth A] Focus chain L [auth B] Focus chain O [auth C] Focus chain R [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.183 (Depositor), 0.193 (DCC)
R-Value Work: 0.155 (Depositor), 0.166 (DCC)
R-Value Observed: 0.157 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.259	α = 88.41
b = 49.359	β = 83.15
c = 116.827	γ = 86.23

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394
