10FM | pdb_000010fm

CryoEM structure of Aldehyde dehydrogenase from Francisella tularensis subsp. tularensis at 3.03A resolution

PDB DOI: https://doi.org/10.2210/pdb10FM/pdb
EM Map EMD-75135: EMDB EMDataResource

Classification: OXIDOREDUCTASE
Organism(s): Francisella tularensis subsp. tularensis
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-01-16 Released: 2026-01-28
Deposition Author(s): Abendroth, J., Davies, D.R., Yang, M., Hoarnyi, P.S., Lorimer, D.D., Edwards, T.E., Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.03 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 10FM

This is version 1.0 of the entry. See complete history.

Literature

CryoEM structure of Aldehyde dehydrogenase from Francisella tularensis subsp. tularensis at 3.03A resolution

Abendroth, J., Davies, D.R., Yang, M., Hoarnyi, P.S., Lorimer, D.D., Edwards, T.E.

To be published.

Macromolecule Content

Total Structure Weight: 222.24 kDa
Atom Count: 14,864
Modeled Residue Count: 1,980
Deposited Residue Count: 2,024
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
aldehyde dehydrogenase (NAD(+))	A, B, C, D	506	Francisella tularensis subsp. tularensis	Mutation(s): 0 Gene Names: FTT_0552 EC: 1.2.1.3
UniProt
Find proteins for Q5NHB4 (Francisella tularensis subsp. tularensis (strain SCHU S4 / Schu 4)) Explore Q5NHB4 Go to UniProtKB: Q5NHB4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5NHB4
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.03 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4.7.0
MODEL REFINEMENT	PHENIX	dev_5420

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-01-28

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036

Revision History (Full details and data files)

Version 1.0: 2026-01-28
Type: Initial release
