10BE | pdb_000010be

Human AGO2 bound to a miR-20a guide and a position 10-11 mismatched target

PDB DOI: https://doi.org/10.2210/pdb10BE/pdb
EM Map EMD-75039: EMDB EMDataResource

Classification: RNA BINDING PROTEIN
Organism(s): Homo sapiens
Expression System: Trichoplusia ni
Mutation(s): No

Deposited: 2026-01-09 Released: 2026-06-03
Deposition Author(s): Savidge, A., Nakanishi, K.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.02 Å
Aggregation State: CELL
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 10BE

This is version 1.0 of the entry. See complete history.

Literature

Human AGO2 bound to a miR-20a guide and position 10-11 mismatched target

Zhang, H., Annasaheb-Adhav, V., Kehling, C., Savidge, A., Shen, Z., Fu, T.M., Nakanishi, K.

To be published.

Macromolecule Content

Total Structure Weight: 112 kDa
Atom Count: 6,757
Modeled Residue Count: 811
Deposited Residue Count: 914
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Protein argonaute-2	C [auth A]	873	Homo sapiens	Mutation(s): 0 Gene Names: AGO2, EIF2C2 EC: 3.1.26
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UKV8 (Homo sapiens) Explore Q9UKV8 Go to UniProtKB: Q9UKV8
PHAROS: Q9UKV8 GTEx: ENSG00000123908
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9UKV8
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 1
Guide RNA	A [auth B]	23	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
Target RNA	B [auth C]	18	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.02 Å
Aggregation State: CELL
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-06-03

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-06-03
Type: Initial release
