6HQA

Molecular structure of promoter-bound yeast TFIID


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Molecular structure of promoter-bound yeast TFIID.

Kolesnikova, O.Ben-Shem, A.Luo, J.Ranish, J.Schultz, P.Papai, G.

(2018) Nat Commun 9: 4666-4666

  • DOI: https://doi.org/10.1038/s41467-018-07096-y
  • Primary Citation of Related Structures:
    6HQA

  • PubMed Abstract:

    Transcription preinitiation complex assembly on the promoters of protein encoding genes is nucleated in vivo by TFIID composed of the TATA-box Binding Protein (TBP) and 13 TBP-associate factors (Tafs) providing regulatory and chromatin binding functions. Here we present the cryo-electron microscopy structure of promoter-bound yeast TFIID at a resolution better than 5 Å, except for a flexible domain. We position the crystal structures of several subunits and, in combination with cross-linking studies, describe the quaternary organization of TFIID. The compact tri lobed architecture is stabilized by a topologically closed Taf5-Taf6 tetramer. We confirm the unique subunit stoichiometry prevailing in TFIID and uncover a hexameric arrangement of Tafs containing a histone fold domain in the Twin lobe.


  • Organizational Affiliation

    Department of Integrated Structural Biology, Equipe labellisée Ligue Contre le Cancer, Institut de Génétique et de Biologie Moléculaire et Cellulaire, Illkirch, 67404, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Taf21,756Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R289 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R289
Go to UniProtKB:  C4R289
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R289
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (90 kDa) of TFIID and SAGA complexes
B, C
722Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R4L4 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R4L4
Go to UniProtKB:  C4R4L4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R4L4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (60 kDa) of TFIID and SAGA complexes
D, E
485Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QW33 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QW33
Go to UniProtKB:  C4QW33
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QW33
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (17 kDa) of TFIID and SAGA complexes, involved in RNA polymerase II transcription initiation153Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4QZS5 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4QZS5
Go to UniProtKB:  C4QZS5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4QZS5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Taf875Komagataella phaffii GS115Mutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Histone-foldH [auth I]64Komagataella phaffii GS115Mutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Histone-foldI [auth H]68Komagataella phaffii GS115Mutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Subunit (61/68 kDa) of TFIID and SAGA complexesJ [auth K]609Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R150 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R150
Go to UniProtKB:  C4R150
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R150
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
TFIID subunit (48 kDa)K [auth J]553Komagataella phaffii GS115Mutation(s): 0
UniProt
Find proteins for C4R420 (Komagataella phaffii (strain GS115 / ATCC 20864))
Explore C4R420
Go to UniProtKB:  C4R420
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC4R420
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)United StatesP50 GM076547 RO1 GM110064
French National Research AgencyFranceANR-15-CE11-0022-01
French National Research AgencyFranceANR-10-LABX-0030-INRT

Revision History  (Full details and data files)

  • Version 1.0: 2018-11-21
    Type: Initial release
  • Version 1.1: 2020-07-29
    Changes: Data collection
  • Version 1.2: 2022-03-30
    Changes: Author supporting evidence, Database references
  • Version 1.3: 2024-10-23
    Changes: Data collection, Structure summary
