2PKE

Crystal structure of haloacid delahogenase-like family hydrolase (NP_639141.1) from Xanthomonas campestris at 1.81 A resolution

• PDB DOI: https://doi.org/10.2210/pdb2PKE/pdb

• Classification: HYDROLASE
• Organism(s): Xanthomonas campestris pv. campestris
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2007-04-17 Released: 2007-05-08
• Deposition Author(s): Joint Center for Structural Genomics (JCSG)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.81 Å
• R-Value Free: 0.229
• R-Value Work: 0.178
• R-Value Observed: 0.181

Literature

Crystal structure of haloacid delahogenase-like family hydrolase (NP_639141.1) from Xanthomonas campestris at 1.81 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 56.34 kDa
• Atom Count: 3,847
• Modelled Residue Count: 461
• Deposited Residue Count: 502
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Haloacid delahogenase-like family hydrolase	A, B	251	Xanthomonas campestris pv. campestris	Mutation(s): 5  Gene Names: NP_639141.1, XCC3796
UniProt
Find proteins for Q8P4B4 (Xanthomonas campestris pv. campestris (strain ATCC 33913 / DSM 3586 / NCPPB 528 / LMG 568 / P 25)) Explore Q8P4B4  Go to UniProtKB:  Q8P4B4

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PEG	H [auth B]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
CL	D [auth A], F [auth B], G [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG	C [auth A], E [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.81 Å
• R-Value Free: 0.229
• R-Value Work: 0.178
• R-Value Observed: 0.181
• Space Group: P 1 2₁ 1
• Diffraction Data: https://doi.org/10.18430/M32PKE

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.16	α = 90
b = 107.1	β = 102.29
c = 62.56	γ = 90

Software Package:

Software Name	Purpose
MolProbity	model building
SHELX	phasing
REFMAC	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
MAR345	data collection
XDS	data reduction
SHELXD	phasing
SHARP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2007-05-08
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Revision History

• Version 1.0: 2007-05-08
  Type: Initial release

• Version 1.1: 2008-05-01
  Changes: Version format compliance
• Version 1.2: 2011-07-13
  Changes: Advisory, Version format compliance
• Version 1.3: 2017-10-18
  Changes: Refinement description
• Version 1.4: 2017-10-25
  Changes: Author supporting evidence
• Version 1.5: 2023-01-25
  Changes: Database references, Derived calculations
• Version 1.6: 2024-10-30
  Changes: Data collection, Refinement description, Structure summary
